Siemens SINAMICS S120 User Manual

Motor Modules Booksize Compact
7.8 Technical data
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
477
Tightening torques
:
1. Firstly, only tighten the nuts by hand.
Tightening torque: 0.5 Nm
2. Then tighten the nuts in the specified sequence 1 to 4.
Tightening torque: 6 Nm
Special points to note in relation to mounting on a cold plate
To improve heat transfer, a heat-conducting medium must be used. Special spherical-
indented heat-conducting foil must be used for this purpose. Every Motor Module Booksize
Compact is supplied with heat-conducting foil cut to the right size. Note the mounting
position of the heat-conducting foil.
Note
•
Also replace the heat-conducting foil when replacing a component.
•
Only use heat-conducting foil released or supplied by Siemens.
Article No.
Heat-conducting foil, 50 mm
6SL3162-6FB01-0AA0
Heat-conducting foil, 75 mm
6SL3162-6FC01-0AA0
7.8
Technical data
7.8.1
Single Motor Modules
Table 7- 9 Technical data Single Motor Modules Booksize Compact (3 A to 18 A)
Motor Modules Booksize Compact
6SL3420–
1TE13-0AA.
1TE15-0AA.
1TE21–0AA.
1TE21–8AA.
Output current
Rated current (l
n
)
Base-load current (I
H
)
Intermittent duty current (I
S6
) 40 %
Peak current (l
max
)
A
AC
A
A
AC
A
AC
3
2.6
3.5
9
5
4.3
6
15
9
7.7
10
27
18
15.3
24
54
Output voltage
V
AC
0 … 0.717 x DC-link voltage
DC link current I
d rated
A
DC
3.6
6
11
22
DC-link voltage
(up to 2000 m above sea level)
V
DC
510 … 720
DC-link capacitance
μF
110
110
110
235
Overvoltage trip
Undervoltage trip
1)
V
DC
V
DC
820 ± 2 %
380 ± 2 %
Electronics power supply
V
DC
24 (20.4 … 28.8)
