Siemens SINAMICS S120 User Manual

Line Modules Booksize
4.7 Basic Line Modules with internal air cooling
Booksize Power Units
238 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
4.7.8
Technical data
Table 4- 50 Technical data: Basic Line Modules
Internal air cooling
6SL3130-
1TE22-0AA0
1TE24-0AA0
1TE31-0AA0
Rated power
kW
20
40
100
Infeed
1)
Rated power S1 duty
Infeed power S6 duty (40 %)
Peak infeed power
kW (P
n
)
kW (P
S6
)
kW (P
max
)
20
26
60
40
52
120
100
130
175
Braking power
Continuous power
Peak power
kW (P
n
)
kW (P
max
)
5
40
10
80
-
-
Supply voltages
Line voltage
Line frequency
Electronics power supply
V
ACrms
Hz
V
DC
3 AC 380 … 480 ±10 % (- 15 % < 1 min)
2)
47 … 63
24 (20.4 … 28.8)
DC link voltage
Overvoltage trip
Undervoltage trip
3)
V
DC
V
DC
V
DC
510 … 720
820 ± 2 %
360 ± 2 %
Input currents
Rated input current:
for AC 400 V
input current:
for AC 380 V / AC 480 V
for AC 400 V; S6 duty (40 %)
for AC 400 V; peak current
A
AC
A
AC
A
AC
A
AC
33
35 / 28
43
100
66
70 / 55
86
199
166
172 / 138
216
290
DC link currents
Rated DC link current:
for 600 V
DC link current:
for 540 V
for 600 V DC; S6 duty (40 %)
for 600 V DC; peak current
A
DC
A
DC
A
DC
A
DC
33.5
37
43
100
67
48
87
200
167
185
217
292
Current carrying capacity
DC link busbars
Reinforced DC link busbars
24 V DC busbars
A
DC
A
DC
A
DC
100
150
20
200
--
20
200
--
20
Electronics current drawn at 24 V DC
A
DC
1
1.4
2.0
Total power loss
(including electronics losses, see Power
loss tables (Page 756))
W 144 283.6 628
DC link capacitance
Basic Line Module
Drive line-up, max.
μF
μF
940
20000
1880
20000
4100
50000
Power factor
4)
cos φ
0.98
0.98
0.98
Circuit breaker
(IEC 60947 and UL)
See Chapter Overcurrent protection using fuses and circuit break-
ers (Page 51)
Rated short-circuit current
SCCR
5)
kA 65 65 65
