Motor Modules Booksize Compact
7.2 Description
Booksize Power Units
462 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Damage through use of incorrect DRIVE-CLiQ cables
Damage or malfunctions can occur on the devices or system when DRIVE-CLiQ cables are
used that are either incorrect or have not been approved for this purpose.
• Only use suitable DRIVE-CLiQ cables that have been approved by Siemens for the
particular application.
Note
Malfunctions due to polluted DRIVE-CLiQ interfaces
Malfunctions can occur in t
he system through the use of polluted DRIVE-CLiQ interfaces.
Cover unused DRIVE-CLiQ interfaces with the supplied blanking covers.
Notes for UL applications
Note
The SINAMICS S120 Motor Modules Booksize Compact provide short
-circuit protection at
he motor output terminals.
A Motor Module Booksize Compact is a power unit (inverter) that provides the power supply
for one motor or several motors. Power is supplied by the DC link of the drive unit. A Motor
Module must be connected to a Control Unit via DRIVE-CLiQ. The open-loop and closed-
loop control functions for the Motor Module are stored in the Control Unit.
1 motor can be connected to Single Motor Modules and 2 motors can be connected to
Double Motor Modules.
Motor Modules Booksize Compact can be used either with cooling type "internal air cooling"
or cooling type "cold plate". The cooling type is selected by parameter (see the SINAMICS
S120/S150 List Manual).
