Siemens SINAMICS S120 User Manual

Line Modules Booksize Compact
5.2 Smart Line Modules Booksize Compact
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
343
Special points to note in relation to mounting on a cold plate
To improve heat transfer, a heat-conducting medium must be used. Special spherical-
indented heat-conducting foil must be used for this purpose. Every Smart Line Module
Booksize Compact is supplied with heat-conducting foil cut to the right size. Note the
mounting position of the heat-conducting foil.
Note
Use heat conducting foil
•
Also replace the heat-conducting foil when replacing a component.
•
Only use heat-conducting foil released or supplied by Siemens.
Table 5- 6 Heat-conducting foil
Article No.
Heat-conducting foil, 100 mm
6SL3162-6FD01-0AA0
5.2.8
Technical data
Table 5- 7 Technical data Smart Line Modules Booksize Compact
Smart Line Module Booksize Compact
6SL3430–
6TE21-6AA.
Rated power
kW
16
Infeed
1)
Rated power S1 duty
Infeed power S6 duty (40 %)
Peak infeed power
kW (P
n
)
kW (P
S6
)
kW (P
max
)
16
21
35
Regenerative feedback
Continuous regenerative power
Peak regenerative power
kW
kW
16
35
Supply voltages
Line voltage
Line frequency
Electronics power supply
V
AC
Hz
V
DC
3 AC 380 … 480 ± 10 % (-15 % < 1 min)
47 … 63
24 (20.4 … 28.8)
DC link voltage
Overvoltage trip
Undervoltage trip
2)
V
DC
V
DC
V
DC
510 … 720
820 ± 2 %
360 ± 2 %
Input currents
Rated input current
at AC 400 V
Input current
at AC 380 V / AC 480 V
at AC 400 V; S6 duty (40 %)
at AC 400 V; peak current
A
AC
A
AC
A
AC
A
AC
27.5
29 / 24.5
35
57.5
