Siemens SINAMICS S120 User Manual

Cabinet design and EMC Booksize
12.11 Notes on electrical cabinet cooling
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
749
NOTICE
Damage to the component through condensation
Condensation on the components can cause them to fail.
• Select the air circuit and arrangement of the cooling equipment in such a way that no
condensation can form on the components.
• If required, an anti-condensation heater must be installed in the cabinet.
If air conditioners are used, the relative air humidity of the expelled air increases as the air in
the air conditioner cools and may exceed the dew point. If the relative humidity of the air
entering the SINAMICS components is over 80% for an extended period of time, it can be
assumed that the insulation of the components will fail as a result of electrochemical
reactions (see System overview (Page 35)). Using air baffle plates, for example, you must
ensure that the cold air expelled from the air conditioner mixes with warm air in the cabinet
before it enters the components. This reduces the relative air humidity to uncritical values.
12.11.3
Cooling clearances
Table 12- 32 Cooling clearances required above and below SINAMICS components
Component
Clearance [mm]
CU320-2
80
Sensor Modules Cabinet-Mounted SMCxx
50
Terminal Modules TMx
50
Line filter for Line Modules 100
Active Interface Modules
80
Line reactors for Line Modules
100
Active Line Modules
16 … 55 kW
80 … 120 kW
80
80 (additional 50 in front of fan)
Smart Line Modules Booksize
80
Smart Line Modules Booksize Compact
80
Basic Line Modules
80
Motor Modules Booksize
< 132 A
132 A/200 A
80
80 (additional 50 in front of fan)
Motor Modules Booksize Compact
80
Braking Module Booksize
80
Braking Module Booksize Compact
80
Control Supply Module
80
Capacitor Module
80
