Xerox Phaser 7100 Service Manual

Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-374
124-314 DC132 01
Although the IOT speed that is stored in the 3 locations are matched, their values are not set (0).
Applicable Fault Code
• 124-314: The IOT productivity switch data was not set at all 3 locations. IOT speed fails (Contents
corrupted. The PWB was replaced.)
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• MCU PWB, PL 12.1.15
• Image Processor PWB, PL 12.4.1
Troubleshooting Procedure
Step Actions and Questions
1. Replace the MCU PWB (REP 12.4 MCU PWB on page 4-206).
2. If the problem persists, replace the I/P PWB (REP 12.17 Image Processor (I/P) PWB on page 4-228).
