CHARGING SYSTEM
8-17
EAS27220
TROUBLESHOOTING
The battery is not being charged.
NOTE:
Before troubleshooting, remove the following part(s):
1.Rear cover
2.Battery cover
3.Left side cover moulding
4.Left side cover
1. Check the fuse.
(Main)
Refer to “CHECKING THE FUSES” on
page 8-106.
NG→
Replace the fuse.
OK↓
2. Check the battery.
Refer to “CHECKING AND CHARG-
ING THE BATTERY” on page 8-107.
NG→
● Clean the battery terminals.
● Recharge or replace the battery.
OK↓
3. Check the stator coil.
Refer to “CHECKING THE STATOR
COIL” on page 8-115.
NG→
Replace the stator assembly.
OK↓
4. Check the charging voltage.
Refer to “CHECKING THE CHARG-
ING VOLTAGE” on page 8-116.
OK→
Charging voltage is OK.
NG↓
5. Check the entire charging system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-15.
NG→
Properly connect or repair the charging system’s
wiring.
OK↓
Replace the rectifier/regulator.
To Next Page
