CHASSIS SPECIFICATIONS
2-9
EAS20300
CHASSIS SPECIFICATIONS
Chassis
Frame type Diamond
Caster angle 28.00 °
Trail 95.0 mm (3.74 in)
Front wheel
Wheel type Cast wheel
Rim size 14M/C x MT3.50
Rim material Aluminum
Wheel travel 120.0 mm (4.72 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Wheel axle bending limit 0.25 mm (0.01 in)
Rear wheel
Wheel type Cast wheel
Rim size 15M/C x MT5.00
Rim material Aluminum
Wheel travel 117.0 mm (4.61 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Wheel axle bending limit 0.25 mm (0.01 in)
Front tire
Type Tubeless
Size 120/70R14 M/C 55H
Manufacturer/model DUNLOP/D252F
Manufacturer/model BRIDGESTONE/TH01F
Wear limit (front) 1.6 mm (0.06 in)
Rear tire
Type Tubeless
Size 160/60R15 M/C 67H
Manufacturer/model DUNLOP/D252
Manufacturer/model BRIDGESTONE/TH01R
Wear limit (rear) 1.6 mm (0.06 in)
Tire air pressure (measured on cold tires)
Loading condition 0–90 kg (0–198 lb)
Front 225 kPa (33 psi) (2.25 kgf/cm
2
) (2.25 bar)
Rear 250 kPa (36 psi) (2.50 kgf/cm
2
) (2.50 bar)
Loading condition XP500 90–188 kg (198–414 lb)
XP500A 90–183 kg (198–403 lb)
XP500W 90–190 kg (198–419 lb)
Front 225 kPa (33 psi) (2.25 kgf/cm
2
) (2.25 bar)
Rear 280 kPa (41 psi) (2.80 kgf/cm
2
) (2.80 bar)
Front brake
Type Dual disc brake
Operation Right hand operation
Front disc brake
Disc outside diameter × thickness 267.0 × 4.0 mm (10.51 × 0.16 in)
Brake disc thickness limit 3.5 mm (0.14 in)
Brake disc deflection limit 0.12 mm (0.0047 in)
