LUBRICATION POINTS AND LUBRICANT TYPES
2-22
EAS20380
CHASSIS
Main and drive axle serration
or
Drive axle spline
or
Chain drive case and taper bearing
Bearing (chain drive case) Chain drive oil
Primary sheave spacer Shell BT grease 3®
Primary sheave nut Shell BT grease 3®
Secondary sheave nut
BEL-RAY assembly
lube®
Primary sheave
BEL-RAY assembly
lube®
Secondary sheave
BEL-RAY assembly
lube®
Swingarm pivot shaft bearing
Crankcase mating surface Yamaha bond No.1215
A.C. magneto lead Yamaha bond No.1215
Cylinder head cover (gasket mating surface) Yamaha bond No.1215
Cylinder head cover (guide stopper mating surface) Yamaha bond No.1215
Right crankcase cover (air duct seal mating surface) Yamaha bond No.1215
Lubrication point Lubricant
E
LS
E
LS
LS
LS
Lubrication point Lubricant
Front wheel oil seal lip
Steering bearings and oil seal lip
Throttle grip inner surface and throttle cables
Brake lever pivoting point and metal-to-metal moving parts (left and right)
Parking brake lock lever cable and parking brake lock lever (cable connection
area)
Sidestand pivoting point, metal-to-metal moving parts
Centerstand shaft pivoting point and metal-to-metal moving parts
Oil seal lip (chain drive case)
Rear wheel drive hub spline
Rear wheel oil seal lip
Passenger footrest pivoting point
LS
LS
LS
LS
LS
LS
LS
LS
LS
LS
LS
