ELECTRICAL COMPONENTS
8-107
WARNING
EWA13310
Never use a fuse with an amperage rating
other than that specified. Improvising or us-
ing a fuse with the wrong amperage rating
may cause extensive damage to the electri-
cal system, cause the lighting and ignition
systems to malfunction and could possibly
cause a fire.
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
4. Install:
● Battery cover
● Rear cover
● Grab bar
Refer to “GENERAL CHASSIS” on page 4-1.
EAS28030
CHECKING AND CHARGING THE BATTERY
WARNING
EWA13290
Batteries generate explosive hydrogen gas
and contain electrolyte which is made of poi-
sonous and highly caustic sulfuric acid.
Therefore, always follow these preventive
measures:
● Wear protective eye gear when handling or
working near batteries.
● Charge batteries in a well-ventilated area.
● Keep batteries away from fire, sparks or
open flames (e.g., welding equipment,
lighted cigarettes).
● DO NOT SMOKE when charging or han-
dling batteries.
● KEEP BATTERIES AND ELECTROLYTE
OUT OF REACH OF CHILDREN.
● Avoid bodily contact with electrolyte as it
can cause severe burns or permanent eye
injury.
FIRST AID IN CASE OF BODILY CONTACT:
EXTERNAL
● Skin — Wash with water.
● Eyes — Flush with water for 15 minutes and
get immediate medical attention.
INTERNAL
● Drink large quantities of water or milk fol-
lowed with milk of magnesia, beaten egg or
vegetable oil. Get immediate medical atten-
tion.
CAUTION:
ECA13660
● This is a sealed battery. Never remove the
sealing caps because the balance between
cells will not be maintained and battery per-
formance will deteriorate.
● Charging time, charging amperage and
charging voltage for an MF battery are dif-
ferent from those of conventional batteries.
The MF battery should be charged as ex-
plained in the charging method illustra-
tions. If the battery is overcharged, the
electrolyte level will drop considerably.
Therefore, take special care when charging
the battery.
NOTE:
Since MF batteries are sealed, it is not possible
to check the charge state of the battery by mea-
suring the specific gravity of the electrolyte.
Therefore, the charge of the battery has to be
checked by measuring the voltage at the battery
terminals.
1. Remove:
● Battery cover
Refer to “GENERAL CHASSIS” on page 4-1.
Fuses
Amperage
rating
Q’ty
Main 30A 1
Headlight 15A 1
Signal
20A
(XP500)
15A
(XP500A)
1
Ignition 10A 1
Radiator fan motor 15A 1
Hazard 10A 1
Fuel injection 10A 1
Backup 10A 1
ABS motor (XP500A) 30A 1
ABS control unit (XP500A) 5A 1
Backup fuse (storage box
light, immobilizer unit, and
meter assembly)
10A 1
Reserve 30A 1
Reserve
20A
(XP500)
1
Reserve 15A 1
Reserve 10A 1
Reserve
5A
(XP500A)
1
To Next Page
