LUBRICATION POINTS AND LUBRICANT TYPES
2-21
EAS20360
LUBRICATION POINTS AND LUBRICANT TYPES
EAS20370
ENGINE
Lubrication point Lubricant
Oil seal lips
O-rings
Bearing and bushes
Crankshaft pins
Piston surfaces
Piston pins and connecting rod small end
Balancer surface
Connecting rod big end thrust surface
Connecting rod bolts and nuts
Crankshaft thrust surface
Crankshaft journals
Camshaft lobs
Camshaft journals
Camshaft cap
Valve stems (intake and exhaust)
Valve stem ends (intake and exhaust)
Cylinder head nut
Water pump impeller shaft
Oil pump shaft
Oil pump rotors (inner and outer)
Oil pump O-ring
Oil cooler union bolt
O-ring (fuel injector assembly) Silicone oil
Starter clutch idle gear inner surface
Starter clutch
Main axle thrust surface
or
LS
LS
E
E
E
E
E
E
M
E
E
M
M
M
M
E
E
M
E
E
LS
E
E
E
E
LS
