SIGNALING SYSTEM
8-25
EAS27290
TROUBLESHOOTING
● Any of the following fail to light: turn signal light, brake light or an indicator light.
● The horn fails to sound.
● The speedometer fails to operate.
● The V-belt replacement indicator fails to come on.
● The fuel meter(meter assembly) fails to operate.
NOTE:
Before troubleshooting, remove the following part(s):
1.Battery cover
2.Rear cover
3.Front cowling
4.Handlebar cover
CHECK THE SIGNALING SYSTEM
The horn fails to sound.
1. Check the fuses.
(Main, ignition, signaling, backup and
lighting system)
Refer to “CHECKING THE FUSES” on
page 8-106.
NG→
Replace the fuse(s).
OK↓
2. Check the battery.
Refer to “CHECKING AND CHARG-
ING THE BATTERY” on page 8-107.
NG→
● Clean the battery terminals.
● Recharge or replace the battery.
OK↓
3. Check the main switch.
Refer to “CHECKING THE
SWITCHES” on page 8-101.
NG→
Replace the main switch.
OK↓
4. Check the entire signaling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-23.
NG→
Properly connect or repair the signaling system’s
wiring.
OK↓
This circuit is OK.
1. Check the horn switch.
Refer to “CHECKING THE
SWITCHES” on page 8-101.
NG→
Replace the left handlebar switch.
OK↓
2. Check the horn.
Refer to “CHECKING THE HORN” on
page 8-116.
NG→
Replace the horn.
OK↓
3. Check the entire signaling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-23.
NG→
Properly connect or repair the signaling system’s
wiring.
OK↓
This circuit is OK.
To Next Page
