Dell PowerConnect 6224 User Manual

Configuring System Information 139
Log File
The Log File contains information about specific log entries, including the time the log was entered, the
log severity, and a description of the log.
To display the Log File, click System
→ Logs → Log File in the tree view.
Figure 6-18. Log File
The Log File Table page contains the following fields:
• Log Index — The Log Number within the Log File Table .
•
Severity — The log severity.
•
Log Time — The time at which the log was entered in the Log File Table .
•
Component — The component being logged.
•
Description — The log description.
Removing Log Information
1. Open the Log File Table page.
2. Click Clear Log .
The log information is removed from the log file table, and the device is updated.
Table 6-12. Log Information Commands
CLI Command Description
clear logging Use to clear messages from the logging buffer.
show logging Displays the state of logging and the syslog messages stored in the
internal buffer.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
