Dell PowerConnect 6224 User Manual

672 Configuring IPv6
IPv6 Routes
The IPv6 Routes menu page contains links to web pages that define and display IPv6 Routes parameters
and data. To display this page, click IPv6
→ IPv6 Routes in the tree view. Following are the web pages
accessible from this menu page:
• IPv6 Route Entry Configuration
•IPv6 Route Table
• IPv6 Route Preferences
• Configured IPv6 Routes
IPv6 Route Entry Configuration
Use the IPv6 Route Entry Configuration page to configure information for IPv6 routes.
To display the page, click IPv6
→ IPv6 Routes → IPv6 Route Entry Configuration in the tree view.
Figure 10-32. IPv6 Route Entry Configuration
The IPv6 Route Entry Configuration page contains the following fields:
• IPv6 Network Prefix/PrefixLength — Enter a valid IPv6 Network Address and Prefix.
•
Next Hop IPv6 Address — Enter an IPv6 Next Hop Address. If the Next Hop IPv6 Address specified is
a Link-local IPv6 Address, specify the Interface for the Link-local IPv6 Next Hop Address. Select
Global or Link-local from the drop-down menu to apply to this address.
•
Preference — Enter a Preference Value for the given route. Valid values are 1 to 255, with the default
as 1.
Configuring IPv6 Route Entry
1. Open the IPv6 Route Entry Configuration page.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
