220 Configuring System Information
SNMP notifications are enabled, and the device is updated.
Enabling Authentication Trap
1. Open the Global Parameters page .
2. Select Enable in the Authentication trap field.
3. Click Apply Changes .
Authentication notifications are enabled, and the device is updated.
Enabling SNMP Notifications Using CLI Commands
For information about the CLI commands that perform this function, see the SNMP Commands chapter
in the
CLI Reference Guide . The following table summarizes the equivalent CLI commands you use to
enable SNMP notifications.
SNMP View Settings
Use this page to create views that define which features of the device are accessible, and which are
blocked. You can create a view that includes or excludes OIDs corresponding to interfaces.
Use the SNMP View Settings page to define SNMP views.
To display the SNMP View Settings page, click System
→ SNMP → View Settings in the tree view.
Table 6-40. SNMP Notifications Commands
CLI Command Description
show snmp engineID Displays the SNMP engine ID.
show snmp engineid Displays the SNMP engine ID.
show trapflags Shows the status of the configurable SNMP traps.
snmp-server enable traps Enables SNMP traps globally or enables specific SNMP traps.
snmp-server engineID local Specifies the Simple Network Management Protocol (SNMP) engine
ID on the local switch.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
