510 Configuring Routing
Displaying IP Statistics Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
• IP Routing Commands
The following table summarizes the equivalent CLI commands for this feature.
IP Interface Configuration
Use the IP Interface Configuration page to update IP interface data for this switch. The IP interface
configuration includes the ability to configure the bandwidth, Destination Unreachable messages, and
ICMP Redirect messages.
To display the page, click Routing
→ IP → Interface Configuration in the tree view.
Figure 9-5. IP Interface Configuration
The IP Interface Configuration page contains the following fields:
• Interface — Select the interface to configure from the drop-down menu. The drop-down menu
contains loopback interfaces and VLANs created from the
Switching → VLAN → VLAN Membership →
Add
page.
Table 9-4. IP Statistics Command
CLI Command Description
show ip stats Displays IP statistical information

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
