Dell PowerConnect 6224 User Manual

Configuring System Information 149
Click Clear All Entries to remove all Host Name IP Mapping entries from the table.
Viewing Dynamic Host Entries Using CLI Commands
For information about the CLI commands that perform this function, see the IP Addressing Commands
chapter in the CLI Reference Guide . The following table summarizes the equivalent CLI commands you
use.
ARP Table
Use the ARP Table page to view ARP parameters for IP interfaces. The ARP table displays the correlation
between each MAC address and its corresponding IP address.
To display the ARP Table page, click System
→ IP Addressing → ARP in the tree view.
Figure 6-29. ARP Table
The ARP Table page contains the following fields:
• IP Address — The station IP address, which is associated with the MAC address filled in below.
•
MAC Address — The station MAC address, which is associated in the ARP table with the IP address.
Table 6-18. Dynamic Host Entries Commands
CLI Command Description
show hosts Displays dynamic host entries that the switch has learned.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
