Configuring Routing 571
Displaying RIP Route Redistribution Summary Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
Routing Information Protocol (RIP) Commands
The following table summarizes the equivalent CLI commands for this feature.
Router Discovery
The Router Discovery protocol is used by hosts to identify operational routers on the subnet. Router
Discovery messages are of two types: “Router Advertisements” and “Router Solicitations.” The protocol
mandates that every router periodically advertise the IP Addresses it is associated with. Hosts listen for
these advertisements and discover the IP Addresses of neighboring routers.
The Router Discovery menu page contains links to web pages that configure and display Router
Discovery data. To display this menu, click Routing
Router Discovery in the tree view. Following are
the web pages accessible from this menu page:
Router Discovery Configuration
•Router Discovery Status
Router Discovery Configuration
Use the Router Discovery Configuration
page to enter or change Router Discovery parameters.
To display the page, click Routing
Router Discovery
Configuration in the tree view.
Table 9-29. RIP Route Redistribution Summary Command
CLI Command Description
show ip rip Displays IP RIP redistribution summary data.
