Dell PowerConnect 6224 User Manual

482 Viewing Statistics and Remote Monitoring
• RMON Commands
The following table summarizes the equivalent CLI commands for this feature.
RMON History Control Statistics
Use the RMON History Control page to maintain a history of statistics on each port. For each interface
(either a physical port or a port-channel), you can define how many buckets exist, and the time interval
between each bucket snapshot.
To display the page, click Statistics/RMON
→ RMON → History Control in the tree view.
Figure 8-8. RMON History Control
The RMON History Control page contains the following fields:
• History Entry — Selects entry number on the RMON History Control Table .
•
Source Interface — Specifies interface from which the history samples are taken.
•
Owner (0–20 characters) — Indicates RMON station or user that requested the RMON information.
•
Max No. of Samples to Keep (1–65535) — Sets the number of historical buckets for this interface.
•
Current No. of Samples in List — Displays the current number of samples taken.
Table 8-7. RMON Commands
CLI Command Description
show rmon statistics Displays RMON Ethernet Statistics.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
