Dell PowerConnect 6224 User Manual

Configuring Switching Information 375
Binding IP Subnets to VLANs Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide :
• VLAN Commands
The following table summarizes the equivalent CLI commands for this feature.
Protocol Group
In a protocol-based VLAN, traffic is bridged through specified ports based on the VLAN’s protocol. User-
defined packet filters determine if a particular packet belongs to a particular VLAN. Protocol-based
VLANs are most often used in situations where network segments contain hosts running multiple
protocols.
Use the Protocol Group page to configure which EtherTypes go to which VLANs, and then enable
certain ports to use these settings.
To display the Protocol Group page, click Switching
→ VLAN → Protocol Group in the tree view.
Table 7-30. IP Subnet - VLAN Binding Commands
CLI Command Description
vlan association subnet Associates an IP subnet to a VLAN
show vlan association subnet Displays the VLAN associated with a specific configured IP subnet.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
