Configuring IP Multicast 771
•
BSR Border
— Specifies the BSR border mode on the PIM interface. This field is not supported for
PIM-DM.
•
Designated Router
— The designated router on the selected PIM interface. For point-to-point
interfaces, this is 0.0.0.0.
Interface Neighbors fields are:
•
Neighbor Count
— The number of PIM neighbors on the selected interface.
•
Neighbor IP
— The IP address of the PIM neighbor for which this entry contains information.
•
Up Time
(hh:mm:ss) — The time since this PIM neighbor (last) became a neighbor of the local router.
•
Expiry Time
(hh:mm:ss) — The minimum time remaining before this PIM neighbor is aged out.
Displaying PIM Interface Summary Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
• PIM-DM or PIM-SM Commands
The following table summarizes the equivalent CLI commands for this feature.
Candidate RP Configuration
The Candidate RP is configured on the Add Candidate RP page. Use the Candidate RP Configuration
page to display and delete the configured rendezvous points (RPs) for each port using PIM.
To access the page, click IPv4 Multicast
→
PIM
→
Candidate RP Configuration or IPv6 Multicast
→
PIM
→
Candidate RP Configuration.
Table 12-35. PIM Interface Summary Commands
CLI Command Description
show ip pimdm interface Displays interface information for PIM-DM on the specified interface.
show ip pimsm interface Displays interface information for PIM-SM on the specified interface.
