Configuring IP Multicast 757
•
Expiry Time
— The cache timer value which indicates the remaining lifetime in
hours:minutes:seconds for each entry.
•
Version1 Host Timer
— The time in hours:minutes:seconds remaining until the local router assumes
that there are no longer any MLD version 1 members on the IP subnet attached to this interface.
When an MLDv1 membership report is received, this timer is reset to the group membership timer.
•
Compatibility
— The compatibility mode (V1, V2) for this multicast group on the specified interface.
•
Filter Mode
— The source filter mode for the specified multicast group on this interface. Possible
values are
Include, Exclude
and
NA
. When
NA
mode is active, this field is blank.
Displaying IPv6 MLD Routing Cache Information Using CLI Commands
For information about the CLI command that performs this function, see the following chapter in the
CLI Reference Guide:
• IPv6 Routing Commands
The following table summarizes the equivalent CLI commands for this feature.
MLD Routing Interface Source List Information
The MLD Routing Interface Source List Information page displays detailed membership information
for an interface. You must configure at least one MLD router interface to access this page. Also, group
membership reports must have been received on the selected interface in order for data to be displayed
here. To access this page, click IPv6 Multicast
→
MLD
→
Routing Interface
→
Source List Information
in the navigation tree.
Table 12-26. IPv6 MLD Routing Cache Information Command
CLI Command Description
show ipv6 mld groups Displays information about multicast groups that MLD reported.
