Dell PowerConnect 6224 User Manual

162 Configuring System Information
Removing a Rule
1. Open the Access Profile page.
2. Click Show All to display the Profile Rules Table page.
3. Select a rule.
4. Check the Remove check box.
5. Click Apply Changes .
The rule is removed, and the device is updated.
Defining Access Profiles Using CLI Commands
For information about the CLI commands that perform this function, see the Management ACL
Commands
chapter in the CLI Reference Guide . The following table summarizes the equivalent CLI
commands you use to define access profiles.
Authentication Profiles
User authentication occurs locally and on an external server. Use the Authentication Profiles page to
select the user authentication method on the device.
To display the Authentication Profiles page, click System
→ Management Security → Authentication
Profiles in the tree view.
Table 6-22. Access Profiles Commands
CLI Command Description
management access-class Defines which management access-list is used.
management access-list Defines a management access-list, and enters the access-list for
configuration.
permit (management) Defines a permit rule.
show management access-class Displays the active management access-list.
show management access-list Displays management access-lists.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
