756 Configuring IP Multicast
The following table summarizes the equivalent CLI commands for this feature.
MLD Routing Interface Cache Information
The MLD Routing Interface Cache Information page displays cache parameters and data for an IP
multicast group address that has been reported to operational MLD routing interfaces. You must
configure at least one MLD router interface to access this page. Also, group membership reports must
have been received on the selected interface in order for data to be displayed here. To access this page,
click IPv6 Multicast
→
MLD
→
Routing Interface
→
Cache Information in the navigation tree.
Figure 12-26. MLD Routing Interface Cache Information
The MLD Routing Interface Cache Information page contains the following fields:
•
Multicast Group IP
— Select the IP multicast group address for which data is to be displayed. Only if
group membership reports have been received on the selected interface can you make this selection,
and the data on this page displays.
•
Interface
— Select the MLD routing interface for which data is displayed.
•
Last Reporter
— The IP Address of the source of the last membership report received for this IP
Multicast group address on the selected interface.
•
Up Time
— The time elapsed in hours:minutes:seconds since this entry was created.
Table 12-25. IPv6 MLD Interface Summary Commands
CLI Command Description
show ipv6 mld interface Displays MLD related information for an interface.
