592 Configuring Routing
VRRP Virtual Router Status
Use the Virtual Router Status page to display virtual router status.
To display the page, click Routing
→ VRRP → Virtual Router Status in the tree view.
Figure 9-50. Virtual Router Status
The Virtual Router Status page displays the following fields:
• VRID — Virtual Router Identifier.
Table 9-39. VRRP Configuration Commands
CLI Command Description
ip vrrp authentication Sets the authorization details value for the virtual router configured on
a specified interface.
ip vrrp ip Sets the virtual router IP address value for an interface.
ip vrrp mode Enables the virtual router configured on an interface. Enabling the
status field starts a virtual router.
ip vrrp preempt Sets the preemption mode value for the virtual router configured on a
specified interface.
ip vrrp priority Sets the priority value for the virtual router configured on a specified
interface.
ip vrrp timers advertise Sets the frequency, in seconds, that an interface on the specified virtual
router sends a virtual router advertisement.
ip vrrp track interface Alters the priority of the VRRP router based on the availability of its
interfaces.
ip vrrp track ip route Tracks route reachability.
vrrp track interface Alters the priority of the VRRP router based on the availability of its
interfaces.
vrrp track ip route Tracks route reachability.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
