Dell PowerConnect 6224 User Manual

Configuring IPv6 629
• Prefer Lifetime — Specifies the prefer lifetime in seconds for delegated prefix.
•
Delete — Deletes the displayed pool prefix delegation configuration when checked and Apply
Changes
is clicked.
Configuring a delegated prefix to a Pool
1. Open the Prefix Delegation Configuration page.
2. Select the pool to be configured.
3. Specify the delegated prefix.
4. Modify the remaining fields as needed.
5. Click Apply Changes .
The delegated prefix and parameters are saved, and the device is updated.
Configuring a delegated prefix Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide :
• DHCPv6 Commands
The following table summarizes the equivalent CLI commands for this feature.
DHCPv6 Pool Summary
Use the Pool Summary page to display settings for all DHCPv6 Pools. At least one pool must be created
using DHCPv6 Pool Configuration before the Pool Summary displays.
To display the page, click IPv6
→ DHCPv6 → Pool Summary in the tree view.
Table 10-8. DHCPv6 Prefix Delegation Command
CLI Command Description
prefix-delegation Defines Multiple IPv6 prefixes within a pool for distributing to specific
DHCPv6 Prefix delegation clients.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
