Dell PowerConnect 6224 User Manual

Configuring System Information 173
Figure 6-46. Add a New User
3. Complete the fields.
4. Click Apply Changes .
The new user is defined, and the device is updated.
NOTE: You can define as many as eight local users on the device.
Displaying Users on the Local User Database
1. Open the Local User Database page.
2. Click Show All to display the Local User Table page.
All members of the local user database are displayed.
Figure 6-47. Local User Table
Removing Users From the Local User Database
1. Open the Local User Database page.
2. Click Show All to display the Local User Table page.
3. Select a User Name .
4. Check Remove .
5. Click Apply Changes .
The user is removed, and the device is updated.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
