230 Configuring System Information
• Community String — Contains a list of user-defined community strings that act as a password and are
used to authenticate the SNMP management station to the device. A community string can contain a
maximum of 20 characters.
•
SNMP Management Station — Contains a list of management station IP address for which
community strings have been defined.
•
Basic — Enables SNMP Basic mode for the selected community. The possible field values are:
–
Access Mode — Defines the access rights of the community. The possible field values are:
•
Read-Only — Community has read only access to the MIB objects configured in the view.
•
Read-Write — Community has read/modify access to the MIB objects configured in the view.
•
Super User — Community has read/modify access to all MIB objects.
–
View Name — Contains a list of user-defined SNMP views.
•
Advanced — Contains a list of user-defined groups. When SNMP Advanced mode is selected, the
SNMP access control rules comprising the group are enabled for the selected community. The
Advanced mode also enables SNMP groups for specific SNMP communities. The SNMP Advanced
mode is defined only with SNMPv3.
•
Remove — When checked, removes a community.
Adding a New Community
1. Open the SNMPv1, 2 Community page.
2. Click Add .
The
Add SNMPv1,2 Community page displays:
Figure 6-97. Add SNMPv1,2 Community
3. Complete the relevant fields.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
