338 Configuring Switching Information
• VLAN ID — Displays the VLAN Tag value.
•
MAC Address — Displays the MAC address.
•
Interface — Displays the port number.
Defining the Aging Time
1. Open the Dynamic Address Table page.
2. Define the Address Aging field.
3. Click Apply Changes .
The aging time is modified, and the device is updated.
Querying the Dynamic Address Table
1. Open the Dynamic Address Table page.
2. Define the parameter by which to query the Dynamic Address Table .
Entries can be queried by
Interface , LAG , MAC Address , or VLAN ID .
3. Click Query to query the Dynamic Address Table.
Removing Data From the Dynamic Address Table
1. Open the Dynamic Address Table page.
2. Check Clear Table .
3. Click Apply Changes .
The
Dynamic Address Table is cleared of all data.
Querying and Sorting Dynamic Addresses Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide :
• Address Table Commands
The following table summarizes the equivalent CLI commands for this feature.
Table 7-19. Dynamic Address Table Commands
CLI Command Description
show bridge address-table Displays dynamically created entries in the bridge forwarding database.
bridge aging-time Sets the aging time of the address.
clear bridge Removes any learned entries from the forwarding database.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
