390 Configuring Switching Information
Figure 7-72. LAG Hash Summary
The LAG Hash Summary page contains a table with the following fields:
• LAGs — Lists the LAG numbers.
•
Hash Algorithm Type — Shows the type of HASH algorithm for unicast traffic flows that is associated
with the LAG.
Viewing the LAG Hash Algorithm Summary Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide :
• Port Channel Commands
The following table summarizes the equivalent CLI commands for this feature.
Table 7-37. LAG Hash Summary Command
CLI Command Description
show interfaces port-channel Displays port-channel information.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
