Dell PowerConnect 6224 User Manual

Configuring Routing 569
2. Select the Configured Source to modify.
3. Change values on this screen as needed.
4. Click Apply Changes
Specified changes are saved, and the device is updated.
Configuring RIP Route Redistribution using CLI Command
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide:
• Routing Information Protocol (RIP) Commands
The following table summarizes the equivalent CLI commands for this feature.
Table 9-28. RIP Route Redistribution Commands
CLI Command Description
redistribute Configures OSPF protocol to allow redistribution of routes from the
specified source protocol/routers.
distribute-list out Specifies the access list to filter routes received from the source
protocol.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
