Configuring IP Multicast 769
• Interface — Select the interface for which data is to be displayed or configured. You must have
configured at least one router interface before configuring or displaying data for a PIM interface,
otherwise an error message is displayed.
•
Admin Mode — Select Enable or Disable from the drop-down menu to set the administrative status
of PIM for the selected interface. The default is Disable.
•
Hello Interval — Enter the number of seconds between PIM hello messages transmitted from the
selected interface. The default value is 30. Valid values are 0 to 65535 seconds.
•
Join Prune Interval — Enter the frequency at which PIM Join/Prune messages are transmitted on this
PIM interface. The valid values are from (0 to 65535). The default value is 60.
•
BSR Border — Indicates whether this interface is enabled or disables to act as a border for all PIM
bootstrap messages. Bootstrap messages do not cross the BSR border.
•
DR Priority — The Designated Router priority value. The router with the highest priority value is
elected as the Designated Router. A shared-media such as Ethernet may have multiple PIM-SM
routers connected to it. A single one of these routers, the DR, acts on behalf of directly connected
hosts with respect to the PIM protocol. This field is applicable for PIM-SM only. The valid values are 0
to 2147483647.
Configuring PIM for an Interface
1. Open the PIM Interface Configuration page.
2. Select the interface to configure from the Interface field.
3. Modify the remaining fields as needed.
4. Click Apply Changes .
The interface configuration is saved, and the device is updated.
Configuring PIM for an Interface Using CLI Commands
For information about the CLI commands that perform this function, see the following chapter in the
CLI Reference Guide:
• PIM-DM or PIM-SM Commands
The following table summarizes the equivalent CLI commands for this feature.
Table 12-34. PIM Interface Commands
CLI Command Description
ip pimdm mode Sets administrative mode of PIM-DM on an interface to enabled.
ip pimsm mode Sets to enabled the administrative mode of PIM-SM multicast routing
on a routing interface.

Dell PowerConnect 6224 Specifications

General

Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Power Supply	100-240 VAC, 50/60 Hz
RAM	128 MB
Flash Memory	32 MB
Layer Support	Layer 2/3
Stacking	Up to 12 units
Weight	12.1 lbs
MAC Address Table Size	16, 000
Jumbo Frame Support	Up to 9, 216 bytes
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
Ports	24 x 10/100/1000BASE-T
VLAN Support	Yes (802.1Q)
Dimensions	17.3 x 13.8 x 1.7 in (440 x 350 x 44 mm)
