Phaser 7500 Printer Service Manual 3-5
Error Messages and Codes
Error Message and Chain-Link Code Summary
The Error Message Summary table lists possible errors, along with the
corresponding code, and page reference for the corrective procedure.
• The Control Panel Message column shows the message as it appears on the
printer’s display when the error codes during normal operation.
• The Chain-Link column lists codes listed on the printer Error History Report and
the Control Panel.
• The Go to Page column references the procedure related to the error.
Use this table to identify the proper procedure to correct the reported error.
Error Message and Chain Link Code Display
Chain Link Control Panel Message Go to Page
General Troubleshooting (page 3-20)
116-324 116-324 Fail 3-20
016-782/
016-784
016-782/ 016-784 Fail 3-21
N/A HDD System Fail 3-23
N/A NET/ USB System Fail 3-26
N/A IOT System Fail 3-27
N/A HDD Job Fail 3-27
N/A General Sensor Failure 3-28
N/A CentreWare Internet Services Failure 3-29
Jam Errors (page 3-31)
071-105 Registration Sensor On Jam (Trays 2/3/4/5) 3-31
072-101 Tray 3 Misfeed 3-32
072-102 Feed Out Sensor On Jam (Tray 3/4) 3-35
072-900 Tray 2 Feed Out Sensor Static Jam 3-36
073-101 Tray 4 Misfeed 3-37
073-102 Feed Out Sensor 3 On Jam (Tray 4) 3-40
073-900 Tray 4 Feed Out Sensor Static Jam 3-41
074-101 Tray 5 Misfeed 3-42
074-900 Tray 5 Feed Out Sensor Static Jam 3-45
075-100 Tray 1 (MPT) Misfeed 3-46
075-103 Tray 1 Feed Out Sensor Off Jam 3-48
075-135 Regi Sensor On Jam (Tray 1) 3-50
077-101 Regi Sensor Off Jam 3-51
077-103 Exit Sensor 1 Off Jam 3-53
