7-4 Phaser 7500 Printer Service Manual

Cleaning and Maintenance

Cleaning the LED Assembly Window

1. Open the Front Door.

2. Rotate the lever on the front left side to unlock it.

3. Open the Imaging Unit cover.

s7500-406

s7500-407
