Phaser 7500 Printer Service Manual 3-23
Error Messages and Codes
HDD System Fail
Always read the following three basic notes regarding the HDD in this machine
model before servicing.
1. HDD Data
2. HDD Initializing
3. HDD Formatting
After reading the basic notes, proceed with the service operations.
HDD Data
Description by HDD partition
Data to be stored in each partition of the Hard Disk
Partition
No.
Volume Capacity Stored Data
1 ide0a 3GB Font, Form/Logo, SMB Folder (Config. txt,
driver)
2 ide0b 3GB Temporary data for Electronic Sort Print
3 ide0c 4GB Report, Private Charge Print, Secure Print,
Sample Set, Delayed Print
4 ide0d 3GB PDL, Mail Temporary (print data before
decompose)
5 ide0e --- Not used in this model
6 ide0f --- Not used in this model
7 ide0g --- Not used in this model
8 ide0h 2GB Job Log (up to 10,000 items), Failure Log,
Audit Log, Device Authentication Data (device,
personal certificate, etc.)
9 ide0i --- Not used in this model
10 ide0j 14GB Log Image Storage Area of Image Log
16 Ide0p 2GB Backup data of Download Firmware, Backup
data of non-volatile data
To Next Page
