Xerox PHASER 7500 Service Manual

1-2 Phaser 7500 Printer Service Manual
General Information
Printer Introduction and Overview
The Phaser 7500 uses LED print heads with an electrophotographic four-color
(YMCK) tandem architecture and intermediate transfer printing process. The
Phaser 7500 delivers color and mono print speed at 35/35-ppm, and resolutions up
to 1200 x 1200 dots-per-inch (dpi). The printer supports Adobe PostScript 3 and
PCL6, USB 2.0, and 10/100/1000 Base-TX Ethernet.
The Phaser 7500 provides a standard 500-Sheet Tray and a 100-Sheet Fold Down
Tray. Tray 1 supports specialty paper, card stock, and envelopes. The standard
paper input is 600 sheets and the maximum input with an optional Trays 3, 4, and
5 is 1600 sheets. The Output Tray holds 400 sheets facedown.
The printer options add memory, paper capacity, and functionality.
• Memory upgrades are available to increase the standard RAM from 512 MB
up to 2.0 GB maximum.
• The Optional Sheet Feeders are available as options: 1 x 500-Sheet Feeder
(not stackable) or 3 x 500-Sheet Feeder.
Technical Support Information
The Xerox Phaser 7500 Service Manual is the primary document used for repairing,
maintaining, and troubleshooting the printer.
To ensure complete understanding of this product, participation in Xerox Phaser
7500 Service Training is strongly recommended. To service this product, Xerox
certification for this product is required.
For updates to the Service Manual, Service Bulletins, knowledge base, etc., go to:
• Xerox Global Service Net - https://www.xrxgsn.com/secure/main.pl
• Service Partners: http://www.office.xerox.com/partners
For further technical support, contact your assigned Xerox Technical Support for
this product.
