Xerox PHASER 7500 - LPH PLL Lock Fail C

Phaser 7500 Printer Service Manual 3-187
Error Messages and Codes
LPH PLL Lock Fail C
LPH PLL lock mechanism failure.
Applicable Chain-Link Code
• 061-388: LPH PLL Lock Fail C
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ LPH Unit (C), PL2.1.2
■ LPH Cable Assy, PL2.2.1
■ LPH Rear PWB (C), PL2.2.5
■ MCU PWB, PL18.3.6
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the Fault History.
Check whether 061-356 LPH
Download Fail Y has occurred.
Has error 061-356 occurred?
Go to
“LPH Download
Data Fail C” on
page 3-155
(error code
061-356).
Replace the
following parts
in sequence:
■ LPH Unit (C)
(REP 2.1,
page 8-18)
■ LPH Cable
Assembly
■ LPH Rear
PWB (C)
(REP 2.4,
page 8-22)
■ MCU PWB
(REP 18.12,
page 8-202)
