3-250 Phaser 7500 Printer Service Manual
Error Messages and Codes
Waste Toner Bottle Not In Position
The Waste Toner Bottle is not in the proper position.
Applicable Chain-Link Code
• 091-910: Waste Bottle Not Position
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Bottle Guide Assy, PL8.2.1
■ Waste Cartridge, PL8.2.19
■ MCU PWB, PL18.3.6
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check that the Bottle Assembly
Guide at the Waste Cartridge and
printer side does not have any
deformation or debris, and that it is
installed properly.
Is the Waste Cartridge installed
properly?
Go to step 2. Install the
Waste
Cartridge
properly
(REP 1.3,
page 8-12).
2 Perform the Toner Waste Cartridge
Sensors test in Diagnostics.
Use a sheet of paper, etc. to block/
clear the light path to the Waste
Toner Bottle Position Sensor.
Does the display change between
High/ Low?
Replace the
MCU PWB
(REP 18.12,
page 8-202).
Go to “General
Sensor Failure”
on page 3-28
to check the
Waste Toner
Bottle Position
Sensor.
