8-104
Phas
er 7500 P
rinter Ser
vice Manua
l
Service P
arts Disassembly
REP 10.
16 Left
Hand Cov
er Assembly
PL10.12.1
1.
Open the Left Hand
Cov
er Assembly.
2.
Remove 4 screws (silver, Tapped
, 8mm)
that secure the Left Hand
Cover
Assembly to the Bracke
t Assembly (x2 locations) and
remove the Left Hand
Cover Asse
mbly.
s7500-168
665
667
