3-104 Phaser 7500 Printer Service Manual
Error Messages and Codes
Motor Drive PWB F2 Blows
Fuse 2 on the Motor Drive PWB has blown.
Note
Remove the cause of Fuse failure before replacing the Motor Drive PWB.
Applicable Chain-Link Code
• 041-345: PWBA Motor Drive F2 Fuse Break Fail
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
1. Check the following parts circuits for overcurrent and overvoltage, grounded
wires, and then replace the faulty parts or repair the circuits, and replace the
Fuse.
• Exit Motor (REP 17.3, page 8-181)
•LV Fan (REP 18.8, page 8-195)
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Exit Motor, PL17.1.15
■ LV Fan, PL18.1.13
■ Fuse
