Tow/RunSwitch
ELECTRICVEHICLE-ELECTRICAL
COMPONENTS
1
3
5
2
4
707
Figure13-5AccessandRemoveElectronicsModuleCover
TOW/RUNSWITCH
SeeGeneralWarningsonpage1-2.
TESTINGTHETOW/RUNSWITCH
SeeTestProcedure3–Tow/RunSwitchonpage12-14.
TOW/RUNSWITCHREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnectingtheBatteries–ElectricVehicles
onpage1-4.
2.RemovetheelectronicsmodulecovertoaccessbacksideoftheT ow/Runswitch(2).SeeElectronicsModule
CoverRemovalonpage13-5.
3.RemoveT ow/Runswitchboot/hexnut(1)(Figure13-6,Page13-7).
4.RemoveTow/Runswitch(2)fromelectronicsmoduleanddisconnectthepinkwire(3)andlightgreenwire(4).
TOW/RUNSWITCHINSTALLATION
1.Installationisreverseofremoval.MakesureatonswitchisalignedwithatpartofD-shapedholeinelectronics
module(Figure13-6,Page13-7).TightenT ow/Runswitchboot/hexnut(1)to16in·lb(1.8N·m).
2.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnectingtheBatteries–
ElectricVehiclesonpage1-4.
