ELECTRICVEHICLE-BATTERYCHARGERGeneralInformation

LIGHTSTATUSSTATUSEXPLANATION

Solidred

Chargererror.Resetchargerpower.SeeResettingPower–External

Chargeronpage15-13.

FlashingorangeChargerunabletocompletecharge.

Solidgreen

Chargingiscomplete.Batterypackisfullycharged.

Flashinggreen

Solidgreen

Chargingisinprogress.Batterypackhasreachedahighstateofcharge.

Off

Flashinggreen

Chargingisinprogress.BatterypackhasNOTreachedahighstateof

charge.

Solidblue

ACpowertochargerispresent.

LONG-TERMSTORAGE

High-frequencychargersaredesignedtobeleftconnectedwithACpowertothechargerduringoff-seasonor

long-termstorage.

2019PrecedentVillager2MaintenanceandServiceManualPage15-5
