GASOLINEVEHICLE-ENGINEOilLevelSensor

6.Pulloillevelsensor(5)outofengine.

OILLEVELSENSORINSTALLATION

1.Lubricateoillevelsensoro-ringwithoilandcarefullyinsertsensor(5)intoengineuntilfullyseated.

2.Securesensor(5)toenginewithtwobolts(4)andtightento80in·lb(9N·m)(Figure20-11,Page20-13).

3.Connectoillevelsensorwire(3)towireharness.

4.Secureoilsensorwire(3)withclamp(2)andbolt(1).Tightenboltto80in·lb(9N·m).

5.Installywheelandfanshroud.SeeIgnitionCoilRemovalonpage20-14.

6.Fillenginetoproperlevelwithcorrecttypeofoil.SeeEngineOil–GasolineVehicle,Section20,Page20-2.

3038

Figure20-11OilLevelSensor–EX40

2019PrecedentVillager2MaintenanceandServiceManualPage20-13
