RearHubsGASOLINEVEHICLE-TRANSAXLE

REARHUBS

REARHUBREMOVAL

1.TurnthekeyswitchtotheOFFpositionandremovethekey,andplacetheForward/Reversehandleinthe

NEUTRALposition.

2.Disconnectbatteryandsparkplugwire(s).

SeeDisconnectingtheBattery-GasolineVehiclesonpage1-3.

3.Placechocksatthefrontwheelsandloosenlugnutsonbothrearwheels.

4.Removetherubberdustcap(1).

5.Removeanddiscardthecotterpin(2)(Figure24-3,Page24-4).

6.Removenutlockingcap(3)andloosenthehubnut(4)ontheaxleshaft.

7.Liftandsupporttherearofvehicle.

8.Removethelugnutsandwheel.

9.Slidebrakedrumoffhub.

10.Removehubnut(4)andlargeatwasher(5)andpullhub(6)offaxleshaft.SeefollowingNOTE.

NOTE:Ifthehub(6)doesnotslideeasilyofftheaxleshaft,useatwoorfour-jawwheelpullertoremovethehub.

3056

Figure24-3RearHubExplodedView

REARHUBINSTALLATION

1.Inspectbrakeshoesforwearandreplaceifnecessary.SeeWheelBrakeAssembliessection.

NOTE:Ifbrakeshoesarereplacedononeside,replacetheoppositesidealso.

2.Cleanthesplinesandthreadedportionoftheaxleshaft.

3.Applyanti-seizecompoundtoboththeaxleshaftsplinesandhub(6)splines.SeefollowingCAUTION.

Page24-42019PrecedentVillager2MaintenanceandServiceManual
