ELECTRICVEHICLE-ELECTRICAL
COMPONENTSMotorControllerOutputRegulator(MCOR)
13
CAUTIO
N
WARNING
WARNING
RUN
TOW
3
4
1
2
709
Figure13-6Tow/RunSwitch
MOTORCONTROLLEROUTPUTREGULATOR(MCOR)
SeeGeneralWarningsonpage1-2.
TESTINGTHEMCOR
SeeTestProcedure11–MCORVoltageonpage12-22andTestProcedure5–KeySwitchandMCORLimit
SwitchCircuitonpage12-16.
MCORREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnectingtheBatteries–ElectricVehicles
onpage1-4.
2.Removepedalgroup.SeePedalGroupRemoval,Section5,Page5-1.
3.Disconnectthetwo-pinandthree-pinconnectorsfromtheMCOR.
4.RemovetheT25torxscrewsecuringtheMCORtothepedalgroup.
5.DetachthetwotabsfromtheacceleratorpedalandremovetheMCORfromvehicle.
MCORINSTALLATION
1.AlignthetwotabsoftheMCOR(2)withtheslotsintheacceleratorpedalonthepedalgroup.InserttheMCOR
intotheacceleratorpedaluntilthetabsengage.SeefollowingNOTE.
NOTE:RotatethepedalbackandforthifnecessarytoaligntheD-shapedendofshaftwiththeMCOR.
2.SecureMCORtopedalgroupwithT25torxscrew.Tightenscrewto19in·lb(2.1N·m).
3.Connectthetwo-pinandthree-pinconnectorsfromthewireharnesstotheMCOR.
4.Installthepedalgroup.SeePedalGroupInstallationonpage5-3.
5.Connectthebatteries.SeeConnectingtheBatteries–ElectricVehiclesonpage1-4.
2019PrecedentVillager2MaintenanceandServiceManualPage13-7
