GASOLINEVEHICLE-CLUTCHESDrivenClutch

DRIVENCLUTCH

SeeGeneralWarningsonpage1-2.

1.Screw,5/16-18X3/4Hex-HeadwithPatch7.Screw,#8-32X3/4,Socket-HeadCap

2.Washer,DrivenClutch8.Button,Drive

3.Ring,Retaining9.Sheave,Movable,Driven

4.Key,DrivenClutch10.Washer,Acetal,DrivenClutch

5.Cam,DrivenClutch11.Sheave,Fixed,Driven

6.Spring,DrivenClutch,55Degree12.Key,3/16in.(4.7mm)SquareX1.50in.(38mm)Long

2961

Figure23-14DrivenClutch–ExplodedView

2019PrecedentVillager2MaintenanceandServiceManualPage23-13
