RearBodyBODYANDTRIM
1
621
Figure4-9UniversalAccessoryMounting
SEATBACKANDSTRUCTURALACCESSORYMODULE(SAM)
SAMRemoval
1.Ifthevehiclehasacanopy,therearuprightsupportsmustberemovedfromtheSAM.
2.Removefourbolts(4)toreleasetheSAM(3)fromthevehicle(Figure4-10,Page4-13).
SAMInstallation
PositiontheSAM(3)overitsmountingholesandsecurewithfourscrews(4).Tightenscrewsto71in·lb(8N·m).
SeatBack
Theseatback(1)issecuredtotheSAM(3)withtwoscrews(2)(Figure4-10,Page4-13).Whenreplacingthe
backrest,tightenscrews(2)to51in·lb(5.8N·m).
BagRackRemoval
1.Removetwoscrews(10)toreleasethebaghoop(6)andrelatedcomponentsfromtheSAM(3)(Figure4-10,
Page4-13).
2.Bagstrap(8)maybereleasedbyremovingtwoplasticbarrelconnectors(9)andonescrew(12).
3.Bagstrapbuckles(7)maybesnappedoutofbaghoop(6).
BagRackInstallation
Installationisthereverseofremoval.Tightenscrew(12)to31in·lb(3.5N·m)andscrews(10)to53in·lb(6N·m).
SweaterBasket
Thesweaterbasket(11)issecuredtothebaghoopassemblybythreescrews(12).T absontheupperedgeofthe
basketalignwithholesinthebaghoop(6)forinstallationpurposes.Tightenscrews(12)to31in·lb(3.5N·m)for
molded-plasticsweaterbasket(Figure4-10,Page4-13).
Page4-122019PrecedentVillager2MaintenanceandServiceManual
