ElectronicsModule

ELECTRICVEHICLE-ELECTRICAL

COMPONENTS

2771

Figure13-8ControllerandSolenoidRemoval

ELECTRONICSMODULEINSTALLATION

1.Returnelectronicsmodule(3)toitslocationinvehiclebutleaveittiltedforward.

2.Completeconnectionstothecontroller(1),theTow/Runswitch(5)andthesolenoid(4)pertheelectrical

schematics.

3.Tightenbolts(6)onthecontrollerto108in·lb(12.2N·m).

4.Tightennuts(7)onthesolenoidto6.4ft·lb(8.7N·m).

Page13-102019PrecedentVillager2MaintenanceandServiceManual
