15
ExternalChargerMountingELECTRICVEHICLE-BATTERYCHARGER
EXTERNALCHARGERMOUNTING
WARNING
•Makesurethechargerissecurelymounted.Donothangthechargerbyitshandle.
•Placeallcordssotheywillnotbesteppedon,trippedover,orotherwisesubjectedtodamageorstress.
CAUTION
•Donotmountthechargerinexceptionallyhotlocations,suchasonatinexteriorwallwithsouthernor
westernexposure,withchargersstackedtogetherandespeciallywithheatsinksnexttoeachother,etc.
•Chargermustnotbesubjectedtowaterspray.
Usethemountingholestosecurethecharger(Figure15-2).Positionthechargersothatishasadequateventilation
andthechargerstatusindicatorpanelisvisible.Thechargercanbemountedinanyorientation(right-sideup,upside
down,etc.)providedthecoolingîš¿nsareunobstructedithasadequateventilation(Figure15-3).
Tohelpensureoptimalchargetimes,mountthechargerinanareawhereambienttemperaturesduringcharging
remainbelow104°F(40°C).SeeThermalCutbackonpage15-4.
2674
Figure15-2ChargerMountingHoles
2675
Figure15-3ExamplesofChargerMountingOrientation
Wheninstallingcharger,incorporatea"driploop"intheACcordtopreventwaterfromrunningdownthecordandinto
theACcordreceptacleonthecharger(Figure15-4,Page15-7).
Page15-62019PrecedentVillager2MaintenanceandServiceManual
