GASOLINEVEHICLE-ELECTRICAL
COMPONENTSVoltageRegulator
19
7.1.Tightennutonbelttensiontool1/2turnandcheckbelttensionwithgauge(Figure19-15,Page19-13).
NOTE:Topreventerrorsinmeasurementcausedbyresidualtension,ensuretoloosen,thenreapply,theUniversal
BeltTensiongaugebetweenmeasurements.
7.2.Continuetotightenin1/2turnincrementsuntilproperbelttensionisachieved.
–Propertensionforausedstarter/generatorbeltis75to85lbf(334to378N).
–Propertensionforanewstarter/generatorbeltis120to130lbf(534to578N).
8.Seatthebelt.
8.1.Removeallothertools.
8.2.Thebelttensiontoolcanbetemporarilyleftinplace.
8.3.Connectbatteryonly.DONOTCONNECTSPARKPLUGWIRE.SeeConnectingtheBattery-Gasoline
Vehiclesonpage1-3.SeefollowingWARNING.
WARNING
•Removeprybarbeforestartingengine.
•EnsureclearancebetweenF2terminalandstarter/generatorbracketbeforestartingengine.
8.4.Engagestarterandcrankengineaminimumof5secondsandamaximumof15secondstofullyseat
thebeltintopulleysandhelpeliminateanyslack.
9.Repeatstep7.
10.Maintaintensionandtightenadjustmentnut(4)to15to18ft·lb(20to24.5N·m).Tightenhexnuts(7)to20to
25ft·lb(27to34N·m)(Figure19-13,Page19-12).
11.Removebelttensiontool.
12.Conrmproperbelttensionwithanalmeasurement.
13.Connectsparkplugwire.
VOLTAGEREGULATOR
SeeGeneralWarningsonpage1-2.
TESTINGTHEVOLTAGEREGULATOR
SeeTestProcedure13–VoltageRegulatoronpage18-27.
VOLTAGEREGULATORREMOVAL
1.Disconnectbatteryandsparkplugwire(s).
SeeDisconnectingtheBattery-GasolineVehiclesonpage1-3.
2.Disconnectthevoltageregulatorconnector(3)fromthewireharness(Figure19-18,Page19-16).
3.Removethevoltageregulatormountingscrew(2)andremovethevoltageregulator(1).
2019PrecedentVillager2MaintenanceandServiceManualPage19-15
